Name:
|
Small-size Fermentation tank Beer Container
|
|
Voltage:
|
220V/380V
|
|
Power(W):
|
2kw
|
|
Dimension(L*W*H):
|
User Requirements
|
|
Weight:
|
100-5000kg
|
|
Capacity:
|
50L-5000L
|
|
Man way:
|
top or side
|
|
Marerial:
|
SUS304,316;
|
|
Fermenter:
|
double layer with cooling jacket
|
|
Place of Origin:
|
Zhejiang, China (Mainland)
|
Features
1 For all kinds of beer's fermenter
2 Various capacities: 100L, 200L, 300L, 500L, 1000L, 2000L, 3000L, 5000L, 8000L..
3 Thickness of stainless board and PU insulation material can be customized, our standard
material is inner wall 3mm sus304,outer wall 1.5mm sus304, insulation 100mm PU
|
|
|
Mash tank
|
Electricity heating tube
|
2KW
|
|
Working capacity
|
50l
|
|
Material
|
S.S.304
|
|
Fermentation tank
|
Working capacity
|
50L
|
|
Material
|
S.S.304
|
|
Conial bottom
|
60 degree
|
|
Ice water tank
|
Working capacity
|
120l
|
|
Material
|
S.S.304
|
|
Mash pump
|
Capacity
|
1T/h
|
|
Power
|
230V/1PH,50hz
0.37 KW.
|
|
Chiller
|
Air cooled
|
|
|
Ice water pump
|
power
|
750w
|
|
Function
|
Transfer cooling water
|
|
Control cabinet
|
Power supply:
|
Single phase, 220V/60hz .
|
|
Automatical controlling
|
PLC
|
|
Outer material
|
SS 304
|
|
Function
|
1) Temp in mashing tank showing
2) Temp and pressure in fermenters auto showing.
3) Temp in cold water tank showing
4) Pump stop and start
|
|
Accessories
|
Soft hose
|
Transfer wort and beer
|
|
Tri clamp
|
Pipes connection
|
|
Sugar Meter
|
0-10 degree and 10-20 degree.
|
|
Measuring Tube
|
finishing S.S.304.
|
|
Air tube and hard pipe
|
Transfer water ect
|
