Hose ID
Inch
|
Part
Number
|
Description
|
Fitting Tube
ID Inch
|
Barb ID Inch
|
Fitting Overall Length
|
|
1/4
|
04HB-04BWT-SS
|
.25" Hose Barb x .25" Buttweld Tube, 316SS
|
0.15
|
0.16
|
1.13
|
|
3/8
|
06HB-06BWT-SS
|
.375" Hose Barb x .375" Buttweld Tube, 316SS
|
0.28
|
0.28
|
1.38
|
|
1/2
|
08HB-08BWT-SS
|
.5" Hose Barb x .5" Buttweld Tube, 316SS
|
0.37
|
0.37
|
1.75
|
|
3/4
|
12HB-12BWT-SS
|
.75" Hose Barb x .75" Buttweld Tube, 316SS
|
0.62
|
0.62
|
2.00
|
|
1
|
16HB-16BWT-SS
|
1" Hose Barb x 1" Buttweld Tube, 316SS
|
0.87
|
0.87
|
2.29
|
|
1-1/2
|
24HBL-24BWT-SS
|
1.5" Long Hose Barb x 1.5" Buttweld Tube, 316SS
|
1.37
|
1.37
|
3.13
|
|
1-1/2
|
24HBS-24BWT-SS
|
1.5" Short Hose Barb x 1.5" Buttweld Tube, 316SS
|
1.37
|
1.37
|
2.29
|
|
2
|
32HBL-32BWT-SS
|
2" Long Hose Barb x 2" Buttweld Tube, 316SS
|
1.84
|
1.84
|
3.50
|
|
2
|
32HBS-32BWT-SS
|
2" Short Hose Barb x 2" Buttweld Tube, 316SS
|
1.84
|
1.84
|
2.39
|
|
2-1/2
|
40HBL-40BWT-SS
|
2.5" Long Hose Barb x 2.5" Buttweld Tube, 316SS
|
2.36
|
2.23
|
4.19
|
|
2-1/2
|
40HBS-40BWT-SS
|
2.5" Short Hose Barb x 2.5" Buttweld Tube, 316SS
|
2.25
|
2.25
|
2.88
|
|
3
|
48HBL-48BWT-SS
|
3" Long Hose Barb x 3" Buttweld Tube, 316SS
|
2.87
|
2.67
|
4.66
|
|
3
|
48HBS-48BWT-SS
|
3" Short Hose Barb x 3" Buttweld Tube, 316SS
|
2.87
|
2.75
|
3.39
|
|
4
|
64HBL-64BWT-SS
|
4" Long Hose Barb x 4" Buttweld Tube, 316SS
|
3.83
|
3.75
|
5.00
|
|
4
|
64HBS-64BWT-SS
|
4" Short Hose Barb x 4" Buttweld Tube, 316SS
|
3.83
|
3.81
|
3.68
|
|
6
|
96HBL-96BWT-SS
|
6" Long Hose Barb x 6" Buttweld Tube, 316SS
|
5.75
|
5.75
|
6.00
|
|
6
|
96HBS-96BWT-SS
|
6" Short Hose Barb x 6" Buttweld Tube, 316SS
|
5.75
|
5.75
|
5.00
|
